3SP-AC Submersible Pump -Lumora Energy

Product

Home Product AC Submersible Pump

3SP

SP Series (with stainless steel impeller) MOTOR AND PUMP Adopted the NEMA standard Insulation class:B Protection grade:IP68 Maximum Diameter φ 70mm Highest temperature of liquid:35℃ OPERATING CONDITIONS Maximum fluid temperature up to +50℃ Maximum sand content:0.25% Maximum immersion:80m Minimum well diameter:3” APPLICATIONS Water supply system Booster Garden and farm irrigation Lowering underground water level Various industrial applications OPTIONS ON REQUEST Special mechanical seal Single phase motor with built-in capacitor

4/6SP SP Series (with stainless steel impeller) MOTOR AND PUMP Rewindable motor Single-phase:220-240V/50Hz Three-phase:380-415V/50Hz Equipwith start control box NEMA dimension standards Curve tolerance according to ISO 9001 OPERATING CONDITIONS Maximum fluid temperature up to+35°C Maximum sand content:0.25% Minimum well diameter: 4" (100mm) APPLICATIONS For water supply from wells or reservoirs For domestic use,for civil and industrial applications For garden use and irrigation OPTIONS ON REQUEST Special mechanical seal Single phase motor with built-in capacitor

4SD SD Series (with plastic impeller) MOTOR AND PUMP Rewindable motor Single-phase:220-240V/50Hz Three-phase:380-415V/50Hz Equip with start control box Pumps are designed by casing stressed NEMA dimension stands curve tolerance according to lSO 9001 OPERATING CONDITIONS Maximum fluid temperature up to +35℃ Maximum sand content:0.25% Minimum well diameter:4”(100mm) APPLICATIONS For water supply from wells or reservoirs For domestic use,for civil and industrial applications For garden use and irrigation OPTIONS ON REQUEST Special mechanical seal Single phase motor with built-in capacitor
